Electric Drop Bolt Door Lock

  • 5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback
  • 5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback
  • 5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback
  • 5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback
5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback

5 Wires Low Temperature Electric Drop Bolt Door Lock Support Time Delay and Signal Feedback

  • Model Number: EB06
  • Application: Metal doors, wooden doors, fireproof doors, glass door
  • Time Delay: 0/3/6/9 second
  • Lock Core Strength: Stainless steel polishing process , Holding force 800KG
  • INQUIRY

Specification


Product Name: Low Temperature Electric Bolt Lock with Time delay and signal feedback

Working voltage: DC 12V/24v

Current: 130mA(Standby),960mA(Start)

Time:  0/3/6/9 second

Suitable: Wooden door , Glass door ,Metal door , Fireproof door

Operating Humidity: 0 ~ 90%(non-condensing)


Features


1. Fail safe operation


2. Low temperature, safe


3. Low power consumption


4. Reverse current protection PCB


5. Reliable locking mechanism


6. Durable and silence operation


7. Full range of optional brackets


8. Suitable for wooden door, glass door, metal door, fireproof door, etc
