Wiegand EM iButton Probe Reader/RFID Card Reader For Access Control System

Features

iButton-EM RFID embedded reader is designed for using in the network and standalone Access Control systems. iButton-EM embedded reader supports 125KHz keys and connects to the controllers via Wiegand-26/34 protocol.

Purpose: ACS reader

Operating frequency: 125KHz/13.56mhz

Key types: RFID (Proximity)

Reader standard: 125khz/13.56mhz

Reader protocol: Wiegand-26, Wiegand-34

RFID reading range: 0-3cm

Anti-vandal case: Yes

Waterproof and dustproof case: Yes

Keys copying protection: Yes

Type of copying protection: Iron Logic Protected

Current consumption: 35mA

Visual indication: 1 x Red LED

Case material: Polyamide

Dimensions (mm): D45 x 25
