Remote Access Control

  • High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions
  • High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions
  • High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions
High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions

High Capacity 10000 Users Metal Standalone Door Access Control Support Remote Control and RFID Card Reader Functions

  • Model Number: A7
  • High Capacity: 10000 users
  • Card type: EM/Mifre
  • Wiegand: Wiegand 26-37 bits input & output
  • INQUIRY

INTRODUCTION



A8 iswaterproof metal keypad Access Control/Wiegand Reader for single door. It adopts Atmel MCU, which ensure stable performance. Multi-format Wiegand input &output, supporting Keypad, ID, HID, IC cards. User capacity is 10000, PIN is 4-6 digits.


It is equipped with an Admin cards, which can add / delete users quickly and have the functions of anti-duress, anti- passback function, and backlit of keyboard.




Features and Benefits


Wide voltage input: AC/DC 10-30V


Ani-duress, Anti-passback for single door


Waterproof, conforms to IP67


Wiegand 26-37 bits input & output


Access by multiple cards/remote control


Can be installed on 86 type box (WMK1)


Keypad output:4 bits, 8 bits, 10 digits virtual number


Pulse Mode, Toggle Mode


Power supply: 10-30V AC/DC


Idle Current: ≤45mA


Active Current:  ≤80mA


Waterproof:  IP67


User Capacity: 10000


Card type:  ID, IC, ID + IC(WMK2), HID customized


Frequency:  EM & HID: 125KHz, Mifare: 13.56MHz


Wiegand Card: 26-37 bits, PIN: 4bits, 8bits(ASCII), 10 digits Virtual Number


Lock Output Load ≤2A


Alarm Output Load ≤2A


Operating Temperature: -40°C~+70°C,(-40°F~158°F)


Operating Humidity:  0~98%RH


Dimensions: 129*44*20mm


Unit Weight: 410g
