  • Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor
  • Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor
  • Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor
  • Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor
  • Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor
Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For OutdoorWaterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For OutdoorWaterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For OutdoorWaterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For OutdoorWaterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor

Waterproof Metal Case Swipe RFID Card Reader Keypads Access Control Systems For Outdoor

  • Model Number: S009
  • Work Voltage: DC9-28V
  • Access ways: cards ,code,card +code.
  • Reading Range: 3~8cm
  • INQUIRY
Specification
Product Name
User Capacity
2000
Card Reading Distance
5~8cm
Current
<30mA (Standby); <60mA (Active)
Wiegand Interface
Wiegand 26 bit
Size
120*58*22mm



Features


Strong Zinc Alloy Electroplated anti-vandal case

Full programming from the keypad

2000 users,Supports Card, PIN, Card + PIN

Can be used as a stand alone keypad

Backlight keys

Wiegand 26 input for connection to external reader or Wiegand 26 output for connection to a controller

Adjustable door output time,alarm time,door open time

Very low power consumption (30mA)

Fast operationg speed,<20ms with 2000 users

Lock output current short circuit protection

Easy to install and program

Built-in light dependent resistor (LDR) for anti tamper

Buili-in buzzer

Red,yellow and green LEDs display the working status
